Mac Plus 12/24-30 + CZone
The Mac Plus 12/24-30 is designed to deliver high efficiency and reliability for various battery types.
- Specifications:
- Battery temperature sensor: Yes, included
- Battery voltage sense: Yes
- Status indicator: Yes, 3-color LED
- Communication protocol: MasterBus, CZone & NMEA 2000
- Output voltage: 20-30 V
- Nominal output voltage: 24 V
- Output voltage stabilization: 2% at extremes of temperatures, load, and input
- Output voltage ripple (peak peak): Max. 1%
- Max. output power: 725 W
- Nominal output power: 675 W
- Max. output current: 30 A
- Output charge current (3-step mode): 30 A
- Nominal input voltage: 12 V
- Input voltage range: 10-16 V
- Max. input current: 50 A
- Galvanic isolation: No
- Voltage limited: Yes
- Efficiency:> 95% (at nominal input voltage, full load); peak 97%
- Parallel configuration: Yes
- Alarm contact: Yes, through MasterBus
- Engine run signal input: Yes (active high/active low)
- DIP switches: Yes, for basic setup
- Dimensions (HxWxD): 255 x 165 x 66 mm; 10.0 x 6.5 x 2.6 inches
- Weight: 2 kg; 4.4 lb
- Compliance: CE, E-Mark, SAE J1171 & ISO 8846 Ignition Protected
- No-load consumption: <2 mA
- Charge characteristic: 3-step+
- Battery types: Flooded, Gel, AGM, Spiral, Lithium Ion, Traction, User-defined
- 3-Step charge option: Yes (DIP switch settings)
- DC consumption: <5 mA
- Connections: 3 x M8 terminal for cable diameters of 10-50 mm²
- Temperature range (ambient): -25 °C to 60 °C; derating> 40
- Cooling: Natural cooling
- Protection degree: IP23
- Protections: Overload, over temperature, DC short circuit, reversed polarity (fuse)
- MasterBus compatible: Yes
