JL Audio TwK 88 Audio Processor
The TwK 88 processes audio between the source and amplifiers. TüN software over USB provides channel equalization, crossover, delay and level adjustment. This product is the eight-analogue-input TwK 88.
Features
- 8 Channels of audio output plus 1 digital PASS-THROUGH
- 80 TOTAL Bands of equalization
- TüN® Software offers quick INPUT/OUTPUT setup and wide selection of eq, crossover, delay and level adjustments
- 8 RCA Inputs or 1 optical input
- Included DRC-200 offers remote audio control
- 2-YEAR Warranty
- System Tuning, Simplified: Engineered to deliver world-class system-tuning capabilities in an easy-to-use format, both the TwK 88 and TwK D8 processors offer 8 channels of crystal-clear analog audio outputs plus an unprocessed optical (Toslink™ device) digital output. The optical output jack lets you expand your system with additional TwK DSPs, if needed.
- Control Via TÜN Interface: To control the tuning horsepower of the TwK system-tuning processors, connect your system via the built-in USB hub to your compatible PC by using the companion TüN software interface. Together, TwK and TüN work to streamline the setup and monitoring of your DSP tuning measurements.
- Powerful Tuning Tools: A flexible input mixer allows left and right input channels to be combined with full control over each input’s level and polarity. A total of 80 bands of graphic or parametric equalization are provided, along with configurable EQ assignment. Precise output level controls, adjustable in 0.5-decibel or 0.1-decibel increments, are fully linkable with other channels in any combination.
- FINE-TUNING For Filters: The TwK series toolset includes a powerful crossover section with fully variable high-bypass and low- pass filters. Crossover slopes are selectable from 6-decibel/octave to 48-decibel/octave (in 6-decibel/octave increments).
Compatible devices
- MM105 — TwK RCA inputs.
- MM105-HR — TwK RCA inputs.
- MM55 — TwK RCA inputs.
- MM55-HR — TwK RCA inputs.
- Fix 82 — Audio output to TwK.
- Fix 86 — Audio output to TwK.
- MX280/4 — TwK RCA outputs to amplifier inputs.
- XDM400/4 — TwK RCA outputs to amplifier inputs.
- DRC-200 — Included controller.
Compatible products and installation
- MediaMaster sources: MM105, MM105-HR, MM55 and MM55-HR through their RCA pre-outs.
- JL Audio interfaces: FiX 82 and FiX 86 through their audio outputs to the TwK.
- JL Audio amplifiers: MX280/4 and XDM400/4 through the TwK RCA outputs. Set amplifier input sensitivity to match.
- Controller: included DRC-200 for level and preset control.
- Setup: computer connected by USB running TüN. Bluetooth tuning is not supported.
In the box
- Processor
- One 5-pin Euroblock connector
- 15-foot USB A/B cable
- 18-foot RJ-45 cable
- DRC-200 wired digital remote controller
- LED mounting grommet
- Two hex nuts
- Two washers
Technical specifications
| Input channels | 8 RCA inputs and 1 S/PDIF optical input |
|---|---|
| Output channels | 8 |
| Physical dimensions (Height) | 47 mm |
| Physical dimensions (Width) | 4.29″ (109 mm) |
| Physical dimensions (Depth) | 6.14″ (156 mm) |
| Weight | 2.58 lbs (1.17 kg) |
| Power supply type | Regulated DC-DC SMPS |
| Operating voltage | 10-16 Vdc |
| Warranty | 2 years |
| Signal-to-Noise Ratio @ 4 V (RMS) | 98 dB |
| THD+N @ Rated Power | 0.02% (20 Hz-20 Khz) |
| Input type | Line-level, Differential-balanced |
| Input voltage range | 250 mV-7.1 V Rms |
| Minimum input voltage | 10 mV Rms |
| Input level setting | TwK-88: Eleven discrete selections from 250 mV-7.1V RMS |
| Analog output | Unbalanced, stereo RCA jacks |
| Digital output | Optical (Toslink) output (S/PDIF) |
| Output impedence | 450 Ω |
| Current consumption (Standby) | <1.5 mA |
| Current consumption (Idle) | 0.7 A |
| Fuse rating | 1 A |
| Latency | Optical – Optical: 4.860 mS Optical – Analog: 4.805 mS TwK-88: Analog – Analog: 5.425 mS TwK-88: Analog – Optical: 5.470 mS |
| Audio resolution | 24 bit/48 Khz |
| Number of EQ bands | 80 (8 × 10) |
| Remote level control | Included (DRC-200) |
| Remote level modes | Master Volume Control + Trim; Master Volume Control + Fader; Zone Control, LED Status Reporting |
