Blue Sea 7197 A-Series White Toggle Circuit Breaker – Single Pole 2.5A

A-Series White Toggle Circuit Breaker – Single Pole 2.5A

• Meets American Boat and Yacht Council (ABYC) standards
• The industry standard circuit breaker for Blue Sea Systems” electrical panels
• Combines swtiching and circuit protection into a single device
• “Trip Free” design cannot be held “ON” during fault current condition

Specifications:

• Amperage: 2.5A AC / 2.5A DC
• Color: White
• Actuator Style: Toggle
• Poles: 1
• Maximum Voltage: 250V AC / 65V DC
• Circuit Breaker Type: Magnetic Hydraulic – trip free
• Interrupt Capacity: 3000A @ 120V AC / 1500A @ 250V AC [TUV] / 3000A @ 250V AC [UL 1077] / 7500A @ 65V DC
• Minimum Operating Temperature: -40° C
• Maximum Operating Temperature: 85° C
• Mounting Screw: 6-32 Stainless Steel
• Mounting Screw Torque: 6 in-lb (0.68 Nm)
• Screw Terminal Torque: 14 in-lb (1.58 Nm)
• Switching Cycles:10000
• Terminal Screw: 10-32 Stainless Steel
• Weight: 0.17lb (0.08 kg)

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Amperage: 2.5a
• Box Dimensions: 1″H x 3″W x 4″L WT: 0.17 lbs
• UPC: 632085071974

SKU:BLU-7197
