BEP DC Panel – 12-Way – No Meter – Horizontal

DC Panel – 12-Way – No Meter – Horizontal

BEP Marine uses the highest quality materials in its range of Control
Panels, from the marine grade aluminium base plates to the Airpax magnetic
hydraulic circuit breakers.

Features

• Marine Grade powder coated aluminium
• Airpax circuit breaker
• Stylish Contour Design fascia
• Green LED backlit labels
• Red LED indicates systems on
• Panels meet ABYC standards

Specifications

Total Positions: 12 Loads
Circuit Breakers: 3X 5A, 4X 10A, 4X 15A, 1X 25A
Nominal Voltage: 12V
Maximum Amperage: 100A
Dimensions: 4.5″ X 13.9″ X 2.5″
Neg Bus: 6 Way

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Voltage: 12v
• AC/DC: DC
• Max Breaker Quantity: 12
• Box Dimensions: 6″H x 6″W x 19″L WT: 3.6 lbs
• UPC: 870216002057

Owner’s Manual (pdf)

SKU:BEP-902NMH
