Home » Shop » Transducers » Airmar B164 1kW 0 Thru-Hull Transducer for Simrad w/Blue Connector [B164-0-BL]

Airmar B164 1kW 0 Thru-Hull Transducer for Simrad w/Blue Connector [B164-0-BL]

Original price was: $839.40.Current price is: $526.61.

Sale!
SKU: B164-0-BL-AIR Category:
Share

B164 1kW 0° Thru-Hull Transducer with Blue Connector

The B164 is a 1kW bronze low-profile transducer with a fast-response temperature sensor. The transducer is ideal for fast, trailered, tournament, sport-fishing boats that cannot install an external fairing. This version has a zero degree tilt for hull deadrise angles of 0-7 degrees.

The BL (Blue Connector) version of the B164 transducer is for Lowrance fishfinders and sounders that use the standard Lowrance 7-pin blue connector. This includes the Lowrance HDS series and many other current and discontinued Lowrance units. The B164 BL version is also for the Simrad NSE series.

Features:

  • Power output 1000W
  • 3.875″ hole size (98mm)
  • Beam 22 x 20° at 50kHz, 6 x 6° at 200kHz
  • Maximum depth 1200-1800 ft @ 50kHz
  • Maximum depth 500-800 ft @ 200kHz

This product may not be returned to the original point of purchase.Please contact the manufacturer directly with any issues or concerns.

Specifications:

  • Mounting Style: Thru-Hull
  • Box Dimensions: 8″H x 10″W x 12″L WT: 10.6 lbs
